Description
Nemtek brackets are made to a high standard to maximise security and ensure long life in the field. The level of security achieved is directly affected by the choice of bracket, the number of wires forming the electrical barrier and the distance between the brackets. Nemtek offers a large range of brackets to suit most wall types and applications. They are made from steel and are finished in a high quality outdoor powder coating, or are hot-dip galvanised for coastal conditions.
Features:
• 20 x 20 x 1.6mm square tube
• Straight and angled
• Multiple wire options
• Hot dip galvanised or hot dip galvanised and powder coated finish
• 995 mm, 1195 mm or 1395 mm long
• Associated insulator: Jurassic insulator slotted
• Ideal for coastal use
Specifications
Material: 20mm X 20mm X1.6mm
Finish: Hot dip galvanised or hot dip galvanised with powder coating
Colour powder coated: Black or White
Stock Code | Name | Description |
---|---|---|
ESQJ-10HDBA/S | Square tube Jurassic bracket | SQ 20*20*1.6mm-10W-Blk- Ang-HDG-Slot |
ESQJ-10HDBS/S | Square tube Jurassic bracket | SQ 20*20*1.6mm-10W-Blk-STR-HDG-Slot |
ESQJ-10HDWA/S | Square tube Jurassic bracket | SQ 20*20*1.6mm-10W-Wht-Ang-HDG-Slot |
ESQJ-10HDWS/S | Square tube Jurassic bracket | SQ 20*20*1.6mm-10W-Wht-STR-HDG-Slot |
ESQJ-6HDBA/PC | Square tube Jurassic bracket | SQ 20*20*1.6mm-Jur-6W HD Ang PC BB-MTO |
ESQJ-6HDBA/S | Square tube Jurassic bracket | SQ 20*20*1.6mm-Jur-6W HD ANG BB-SLOT |
ESQJ-6HDBS/PC | Square tube Jurassic bracket | SQ 20*20*1.6mm-Jur-6W HD Str PC BB-MTO |
ESQJ-6HDBS/S | Square tube Jurassic bracket | SQ 20*20*1.6mm-Jur-6W HD STR BB-SLOT |
ESQJ-8HDBA/PC | Square tube Jurassic bracket | SQ 20*20*1.6mm-Jur-8W HD ANG PC BB-MTO |
ESQJ-8HDBA/S | Square tube Jurassic bracket | SQ 20*20*1.6mm-Jur-8W HD ANG BB-SLOT |
ESQJ-8HDBS/PC | Square tube Jurassic bracket | SQ 20*20*1.6mm-Jur-8W HD STR PC BB-MTO |
ESQJ-8HDBS/S | Square tube Jurassic bracket | SQ 20*20*1.6mm-Jur-8W HD STR BB-SLOT |
