Dahua Fixed Lens HAC-HDW1200TL-A IR Eyeball Camera

Description

The Dahua Fixed Lens HAC-HDW1200TL-A IR Eyeball Camera is a high-performance surveillance solution designed for both indoor and outdoor environments. With its advanced features and robust construction, it ensures reliable security monitoring for various applications.

Key Features:

• High-Definition Video: Captures crisp 1080P full HD footage at a maximum frame rate of 30 frames per second, delivering clear and detailed images.

• HD and SD Output Switchable: Offers flexibility with switchable high-definition (HD) and standard-definition (SD) outputs, allowing compatibility with various recording devices.

• Fixed Lens Options: Equipped with a 3.6mm fixed lens, with an optional 2.8mm lens available, providing different field-of-view options to suit specific monitoring needs.

• Built-in Microphone: Features an integrated microphone, enabling audio recording alongside video footage for comprehensive surveillance.

• Smart IR Technology: Utilizes Smart IR with a maximum infrared (IR) length of 30 meters, ensuring optimal low-light performance and preventing overexposure in night vision mode.

• Weatherproof Design: Rated IP67 for water and dust resistance, making it suitable for challenging environmental conditions.

Specifications:

• Image Sensor: 1/2.7-inch CMOS sensor with 2MP effective pixels (1920 horizontal × 1080 vertical).

• Minimum Illumination: 0.02 Lux at F1.9 (30 IRE); 0 Lux with IR on, ensuring visibility in low-light conditions.

• IR Distance: Effective up to 30 meters (98.4 feet), providing extended night vision capabilities.

• Lens Type: Fixed-focal with M12 mount; available in 2.8mm and 3.6mm focal lengths.

• Field of View:

  • 2.8mm lens: Diagonal: 119°, Horizontal: 101°, Vertical: 54°.
  • 3.6mm lens: Diagonal: 100°, Horizontal: 84°, Vertical: 45°.

• Video Frame Rate:

  • HDCVI: 1080P at 25/30fps; 720P at 25/30/50/60fps.
  • AHD/TVI: 1080P at 25/30fps; 720P at 25/30/50/60fps.
  • CVBS: 960H.

• Day/Night Mode: Automatic switch via IR-cut filter (ICR) for seamless transition between day and night monitoring.

• Backlight Compensation: Supports BLC, HLC, and DWDR to enhance image quality in challenging lighting conditions.

• Noise Reduction: 2D NR technology reduces image noise, ensuring clearer footage.

• Power Supply: Operates on 12V DC with a maximum power consumption of 3.3W (IR on).

• Operating Temperature: Designed to function in temperatures ranging from -40°C to +60°C (-40°F to 140°F) with less than 95% non-condensing humidity.

• Dimensions and Weight: Measures φ97.0 mm × 85.8 mm (φ3.82″ × 3.38″) and weighs 0.22 kg (0.49 lb).

Additional Information:

The Dahua Fixed Lens HAC-HDW1200TL-A IR Eyeball Camera is an ideal choice for those seeking a reliable and durable surveillance camera with high-definition imaging, audio recording, and robust night vision capabilities. Its weatherproof design and flexible output options make it suitable for a wide range of security installations. The effective IR range is up to 30 meters, making it suitable for short to medium-range surveillance applications.

For more detailed specifications o the Dahua HAC-HDW1200TL-A 2MP HDCVI IR Eyeball Camera, please refer to the official datasheet.
